  • TUNGALOY SVJCL2525M16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.984 Shank
Picture of TUNGALOY SVJCL2525M16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.984 Shank

TUNGALOY SVJCL2525M16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.984 Shank

ANSI: SVJCL2525M16

ISO: SVJCL2525M16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6807400
Delivery date: 3-5 days
$160.10

Important Notes

Posi,J style, 93deg Approach

Details

Screw-on clamp toolholder with 93deg approach angle, for positive 35deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Insert Type Positive
Application Ext.Turning
Package Size 1
Dimensional Specifications
Machine Side Connection Size 0.9843 25.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Clearance Angle 50.0°
Lead Angle 93°
Insert Size Ic 16 "33"
Overall Len 5.9055 150.00MM
Shank/Pilot Dia 0.9843 25.00MM
Cutting & Machining Properties
Insert Style VC
Hand R/L Left
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
