  • TUNGALOY SVJCL2020K16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.787 Shank
Picture of TUNGALOY SVJCL2020K16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.787 Shank

TUNGALOY SVJCL2020K16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.787 Shank

ANSI: SVJCL2020K16

ISO: SVJCL2020K16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6807399
Delivery date: 3-5 days
$138.10

Important Notes

Posi,J style, 93deg Approach

Details

Screw-on clamp toolholder with 93deg approach angle, for positive 35deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Package Size 1
Insert/Tool Tool
Insert Type Positive
Application Ext.Turning
Dimensional Specifications
Clearance Angle 50.0°
Overall Len 4.9213 125.00MM
Machine Side Connection Size 0.7874 20.00MM
Shank/Pilot Dia 0.7874 20.00MM
Insert Size Ic 16 "33"
Tool Material Steel
Machine Side Connection Type Stick Tool
Lead Angle 93°
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 35.0°
Insert Style VC
Inter/Extern External
Hand R/L Left
