  • TUNGALOY SVJCL1616H16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank
Picture of TUNGALOY SVJCL1616H16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank

TUNGALOY SVJCL1616H16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank

ANSI: SVJCL1616H16

ISO: SVJCL1616H16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6807398
Delivery date: 3-5 days
$127.00

Important Notes

Posi,J style, 93deg Approach

Details

Screw-on clamp toolholder with 93deg approach angle, for positive 35deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Made In USA No
Insert Type Positive
Insert Application General Purpose
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 16 "33"
Clearance Angle 50.0°
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 3.9370 100.00MM
Lead Angle 93°
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
Insert Style VC
Hand R/L Left
