Picture of TUNGALOY STCL16-27 On Edge Cut Off,Grooving Stick Tool Steel Square 1.000 Shank

TUNGALOY STCL16-27 On Edge Cut Off,Grooving Stick Tool Steel Square 1.000 Shank

ANSI: STCL16-27

ISO: STCL16-27

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6883414
Delivery date: 3-5 days
$190.80

Details

Precision external grooving tools with uniquely shaped insert with 4 cutting edges

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Insert Application General Purpose
Application Swiss, Ext.Grooving, Parting
Shipping State Illinois
Made In USA No
Insert/Tool Tool
Package Size 1
Dimensional Specifications
Insert Size Ic 27
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Overall Len 5.5000 139.70MM
Cutting & Machining Properties
Insert Style TC
Hand R/L Left
Insert Shape/Cutter Pocket Shape Triangle
Inter/Extern External
