  • TUNGALOY SSDPN1616H Stick Tool Square Insert Posi,D style, 45deg Approach , Steel Square 0.629 Shank
Picture of TUNGALOY SSDPN1616H Stick Tool Square Insert Posi,D style, 45deg Approach , Steel Square 0.629 Shank

TUNGALOY SSDPN1616H Stick Tool Square Insert Posi,D style, 45deg Approach , Steel Square 0.629 Shank

ANSI: SSDPN1616H

ISO: SSDPN1616H

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6807323
Delivery date: 3-5 days
$92.35

Important Notes

Posi,D style, 45deg Approach

Details

Screw-on clamp toolholder with 45deg approach angle, for positive square inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Clearance Angle 40.0°
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Insert Size Ic 09 "32"
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 3.9370 100.00MM
Lead Angle 45°
Cutting & Machining Properties
Inter/Extern External
Insert Shape/Cutter Pocket Shape Square
Insert Style SP
Hand R/L Neutral
