Picture of TUNGALOY SDJCL123 Stick Tool 55.0° Insert Posi,J style, 93deg Approach , Steel Square 0.750 Shank

TUNGALOY SDJCL123 Stick Tool 55.0° Insert Posi,J style, 93deg Approach , Steel Square 0.750 Shank

ANSI: SDJCL123

ISO: SDJCL123

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6864101
Delivery date: 3-5 days
$131.90

Important Notes

Posi,J style, 93deg Approach

Details

Screw-on clamp toolholder with 93deg approach angle, for positive 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Insert Type Positive
Dimensional Specifications
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Clearance Angle 27.0°
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.7500 19.05MM
Overall Len 4.5000 114.30MM
Lead Angle 93°
Insert Size Ic 11 "32"
Cutting & Machining Properties
Inter/Extern External
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DC
Hand R/L Left
