  • TUNGALOY S50U-PDUNR15 Boring Bar 55.0° Insert Neg,U style, 93deg Approach , Steel Round 1.968 Shank
Picture of TUNGALOY S50U-PDUNR15 Boring Bar 55.0° Insert Neg,U style, 93deg Approach , Steel Round 1.968 Shank

TUNGALOY S50U-PDUNR15 Boring Bar 55.0° Insert Neg,U style, 93deg Approach , Steel Round 1.968 Shank

ANSI: S50U-PDUNR15

ISO: S50U-PDUNR15

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6806093
Delivery date: 3-5 days
$656.20

Important Notes

Neg,U style, 93deg Approach

Details

Lever-lock boring bar, for Negative 55deg rhombic insert

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Int.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Tool Material Steel
Lead Angle 93°
Machine Side Connection Size 1.9685 50.00MM
Shank/Pilot Dia 1.9685 50.00MM
Min Bore 2.4803
Clearance Angle 50.0°
Insert Size Ic 12 "43"
Machine Side Connection Type Boring Bar
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Hand R/L Right
Inter/Extern Internal
