Picture of TUNGALOY S50U-PCLNR12 Boring Bar 80.0° Insert Steel Round 1.968 Shank

TUNGALOY S50U-PCLNR12 Boring Bar 80.0° Insert Steel Round 1.968 Shank

ANSI: S50U-PCLNR12

ISO: S50U-PCLNR12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6806091
Delivery date: 3-5 days
$626.85

Details

Lever-lock boring bar, for Negative 80deg rhombic insert

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Int.Turning
Insert/Tool Tool
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Package Size 1
Dimensional Specifications
Machine Side Connection Size 1.9685 50.00MM
Shank/Pilot Dia 1.9685 50.00MM
Min Bore 2.4803
Insert Size Ic 12 "43"
Lead Angle 95°
Tool Material Steel
Machine Side Connection Type Boring Bar
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 80.0°
Inter/Extern Internal
Insert Style CN
Hand R/L Right
