  • TUNGALOY S16M-PCLNR09 Boring Bar 80.0° Insert Neg,L style, 95deg Approach , Steel Round 0.629 Shank
Picture of TUNGALOY S16M-PCLNR09 Boring Bar 80.0° Insert Neg,L style, 95deg Approach , Steel Round 0.629 Shank

TUNGALOY S16M-PCLNR09 Boring Bar 80.0° Insert Neg,L style, 95deg Approach , Steel Round 0.629 Shank

ANSI: S16M-PCLNR09

ISO: S16M-PCLNR09

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805983
Delivery date: 3-5 days
$195.30

Important Notes

Neg,L style, 95deg Approach

Details

Lever-lock boring bar, for Negative 80deg rhombic insert

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Package Size 1
Application Int.Turning
Insert/Tool Tool
Dimensional Specifications
Insert Size Ic 09 "32"
Tool Material Steel
Machine Side Connection Type Boring Bar
Lead Angle 95°
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Min Bore 0.7874
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 80.0°
Insert Style CN
Inter/Extern Internal
