  • TUNGALOY PVQNL163-CHP Stick Tool 35.0° Insert Neg,Q/H style, 45deg Approach , Steel Square 1.000 Shank
Picture of TUNGALOY PVQNL163-CHP Stick Tool 35.0° Insert Neg,Q/H style, 45deg Approach , Steel Square 1.000 Shank

TUNGALOY PVQNL163-CHP Stick Tool 35.0° Insert Neg,Q/H style, 45deg Approach , Steel Square 1.000 Shank

ANSI: PVQNL163-CHP

ISO: PVQNL163-CHP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6755260
Delivery date: 3-5 days
$431.75

Important Notes

Neg,Q/H style, 45deg Approach

Details

Lever lock type toolholder with 117.5deg approach angle, for negative 35deg or 25deg rhombic inserts, with channels for high pressure coolant

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Lead Angle 117.5°
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Overall Len 6.0000 152.40MM
Clearance Angle 25.0°
Insert Size Ic 16 "33"
Tool Material Steel
Machine Side Connection Type Stick Tool
Cutting & Machining Properties
Insert Style VN
Hand R/L Left
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
