  • TUNGALOY PVJNL162.33-CHP Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 1.000 Shank
Picture of TUNGALOY PVJNL162.33-CHP Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 1.000 Shank

TUNGALOY PVJNL162.33-CHP Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 1.000 Shank

ANSI: PVJNL162.33-CHP

ISO: PVJNL162.33-CHP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6759392
Delivery date: 3-5 days
$431.75

Important Notes

EcoTurn Toolholders Neg,J style, 93deg Approach

Details

Lever lock type toolholders with 93deg approach angle for negative 35deg rhombic inserts VN**2.33... with channels for high pressure coolant

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Clearance Angle 50.0°
Shank/Pilot Dia 1.0000 25.40MM
Lead Angle 93°
Machine Side Connection Size 1.0000 25.40MM
Overall Len 6.0000 152.40MM
Insert Size Ic 12 "2.3"
Tool Material Steel
Machine Side Connection Type Stick Tool
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 35.0°
Insert Style VN
Hand R/L Left
Inter/Extern External
