  • TUNGALOY PVJNL122.33-CHP Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 0.750 Shank
Picture of TUNGALOY PVJNL122.33-CHP Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 0.750 Shank

TUNGALOY PVJNL122.33-CHP Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 0.750 Shank

ANSI: PVJNL122.33-CHP

ISO: PVJNL122.33-CHP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6759390
Delivery date: 3-5 days
$383.15

Important Notes

EcoTurn Toolholders Neg,J style, 93deg Approach

Details

Lever lock type toolholders with 93deg approach angle for negative 35deg rhombic inserts VN**2.33... with channels for high pressure coolant

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Application Ext.Turning
Package Size 1
Dimensional Specifications
Clearance Angle 50.0°
Insert Size Ic 12 "2.3"
Lead Angle 93°
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.7500 19.05MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Overall Len 4.5000 114.30MM
Cutting & Machining Properties
Insert Style VN
Hand R/L Left
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
