  • TUNGALOY PTGNL1623-CHP Stick Tool Triangle Insert EcoTurn Toolholders , Neg,G style, 91deg Approach , Steel Square 1.000 Shank
Picture of TUNGALOY PTGNL1623-CHP Stick Tool Triangle Insert EcoTurn Toolholders , Neg,G style, 91deg Approach , Steel Square 1.000 Shank

TUNGALOY PTGNL1623-CHP Stick Tool Triangle Insert EcoTurn Toolholders , Neg,G style, 91deg Approach , Steel Square 1.000 Shank

ANSI: PTGNL1623-CHP

ISO: PTGNL1623-CHP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6755240
Delivery date: 3-5 days
$308.50

Important Notes

EcoTurn Toolholders Neg,G style, 91deg Approach

Details

Lever lock type toolholder with 91deg approach angle, for negative triangle inserts TN**23..., with channels for high pressure coolant

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Overall Len 6.0000 152.40MM
Lead Angle 91°
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Insert Size Ic 16 "33"
Tool Material Steel
Machine Side Connection Type Stick Tool
Cutting & Machining Properties
Inter/Extern External
Insert Style TN
Hand R/L Left
Insert Shape/Cutter Pocket Shape Triangle
