  • TUNGALOY PDJNR1616H1104 Stick Tool 55.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 0.629 Shank
Picture of TUNGALOY PDJNR1616H1104 Stick Tool 55.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 0.629 Shank

TUNGALOY PDJNR1616H1104 Stick Tool 55.0° Insert EcoTurn Toolholders , Neg,J style, 93deg Approach , Steel Square 0.629 Shank

ANSI: PDJNR1616H1104

ISO: PDJNR1616H1104

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6710293
Delivery date: 3-5 days
$80.75

Important Notes

EcoTurn Toolholders Neg,J style, 93deg Approach

Details

Lever lock type toolholder with 93deg approach angle, for negative 55deg rhombic inserts DN**1104...

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Shank/Pilot Dia 0.6299 16.00MM
Machine Side Connection Size 0.6299 16.00MM
Insert Size Ic 11 "33"
Tool Material Steel
Machine Side Connection Type Stick Tool
Clearance Angle 27.0°
Overall Len 3.9370 100.00MM
Lead Angle 93°
Cutting & Machining Properties
Hand R/L Right
Inter/Extern External
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
