  • TUNGALOY PDJNR1616H11 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.629 Shank
Picture of TUNGALOY PDJNR1616H11 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.629 Shank

TUNGALOY PDJNR1616H11 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.629 Shank

ANSI: PDJNR1616H11

ISO: PDJNR1616H11

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805629
Delivery date: 3-5 days
$80.75

Important Notes

Neg,J style, 93deg Approach

Details

Lever lock type toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Ext.Turning
Package Size 1
Dimensional Specifications
Insert Size Ic 11 "33"
Tool Material Steel
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Clearance Angle 27.0°
Machine Side Connection Type Stick Tool
Overall Len 3.9370 100.00MM
Lead Angle 93°
Cutting & Machining Properties
Hand R/L Right
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Inter/Extern External
