  • TUNGALOY PDJNL164-CHP Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 1.000 Shank
Picture of TUNGALOY PDJNL164-CHP Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 1.000 Shank

TUNGALOY PDJNL164-CHP Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 1.000 Shank

ANSI: PDJNL164-CHP

ISO: PDJNL164-CHP

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6730832
Delivery date: 3-5 days
$308.50

Important Notes

Neg,J style, 93deg Approach

Details

Lever lock type toolholder for negative 55deg rhombic inserts, with channels for high pressure coolant

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert Type Negative
Made In USA No
Insert/Tool Tool
Insert Application General Purpose
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 12 "43"
Overall Len 6.0000 152.40MM
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Clearance Angle 27.0°
Tool Material Steel
Machine Side Connection Type Stick Tool
Lead Angle 93°
Cutting & Machining Properties
Insert Style DN
Inter/Extern External
Insert Shape/Cutter Pocket Shape 55.0°
Hand R/L Left
