  • TUNGALOY PDJNL1616H11 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.629 Shank
Picture of TUNGALOY PDJNL1616H11 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.629 Shank

TUNGALOY PDJNL1616H11 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.629 Shank

ANSI: PDJNL1616H11

ISO: PDJNL1616H11

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805621
Delivery date: 3-5 days
$80.75

Important Notes

Neg,J style, 93deg Approach

Details

Lever lock type toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Insert Size Ic 11 "33"
Clearance Angle 27.0°
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 3.9370 100.00MM
Lead Angle 93°
Cutting & Machining Properties
Inter/Extern External
Insert Style DN
Insert Shape/Cutter Pocket Shape 55.0°
Hand R/L Left
