Picture of TUNGALOY PCLNR2020 Stick Tool 80.0° Insert Steel Square 0.787 Shank

TUNGALOY PCLNR2020 Stick Tool 80.0° Insert Steel Square 0.787 Shank

ANSI: PCLNR2020

ISO: PCLNR2020

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805611
Delivery date: 3-5 days
$85.30

Details

Lever lock type toolholder with 95deg approach angle, for negative 80deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Ext.Turning
Insert/Tool Tool
Dimensional Specifications
Overall Len 4.9213 125.00MM
Insert Size Ic 12 "43"
Lead Angle 95°
Machine Side Connection Size 0.7874 20.00MM
Shank/Pilot Dia 0.7874 20.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Cutting & Machining Properties
Hand R/L Right
Insert Shape/Cutter Pocket Shape 80.0°
Insert Style CN
Inter/Extern External
