Picture of TUNGALOY PCLNR1616H12E Stick Tool 80.0° Steel Square 0.629 Shank

TUNGALOY PCLNR1616H12E Stick Tool 80.0° Steel Square 0.629 Shank

ANSI: PCLNR1616H12E

ISO: PCLNR1616H12E

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6814276
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Details

Lever lock type toolholder with 95deg approach angle, for negative 80deg rhombic inserts

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Made In USA No
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 12 "43"
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 3.9370 100.00MM
Lead Angle 95°
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Cutting & Machining Properties
Hand R/L Right
Insert Shape/Cutter Pocket Shape 80.0°
Insert Style CN
Inter/Extern External
