Picture of TUNGALOY PCLNL2525M12E Stick Tool 80.0° Steel Square 0.984 Shank

TUNGALOY PCLNL2525M12E Stick Tool 80.0° Steel Square 0.984 Shank

ANSI: PCLNL2525M12E

ISO: PCLNL2525M12E

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6814272
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Details

Lever lock type toolholder with 95deg approach angle, for negative 80deg rhombic inserts

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Shipping State Illinois
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Dimensional Specifications
Overall Len 5.9055 150.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.9843 25.00MM
Lead Angle 95°
Shank/Pilot Dia 0.9843 25.00MM
Insert Size Ic 12 "43"
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 80.0°
Hand R/L Left
Insert Style CN
Inter/Extern External
