Picture of TUNGALOY PCLNL1616 Stick Tool 80.0° Insert Steel Square 0.629 Shank

TUNGALOY PCLNL1616 Stick Tool 80.0° Insert Steel Square 0.629 Shank

ANSI: PCLNL1616

ISO: PCLNL1616

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805596
Delivery date: 3-5 days
$80.75

Details

Lever lock type toolholder with 95deg approach angle, for negative 80deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Stick Tool
Lead Angle 95°
Machine Side Connection Size 0.6299 16.00MM
Insert Size Ic 12 "43"
Shank/Pilot Dia 0.6299 16.00MM
Overall Len 3.9370 100.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 80.0°
Insert Style CN
Inter/Extern External
Hand R/L Left
