  • TUNGALOY MVVNN2020K16 Stick Tool 35.0° Insert Neg,V style, 72.5deg Approach , Steel Square 0.787 Shank
Picture of TUNGALOY MVVNN2020K16 Stick Tool 35.0° Insert Neg,V style, 72.5deg Approach , Steel Square 0.787 Shank

TUNGALOY MVVNN2020K16 Stick Tool 35.0° Insert Neg,V style, 72.5deg Approach , Steel Square 0.787 Shank

ANSI: MVVNN2020K16

ISO: MVVNN2020K16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805514
Delivery date: 3-5 days
$172.30

Important Notes

Neg,V style, 72.5deg Approach

Details

Multi-clamp toolholder with 72.5deg approach angle, for negative 35deg, 25deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 16 "33"
Tool Material Steel
Machine Side Connection Type Stick Tool
Clearance Angle 70.0°
Machine Side Connection Size 0.7874 20.00MM
Lead Angle 72.5°
Overall Len 4.9213 125.00MM
Shank/Pilot Dia 0.7874 20.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
Hand R/L Neutral
Insert Style VN
