  • TUNGALOY MVQNL2020K16 Stick Tool 35.0° Insert Neg,Q/H style, 45deg Approach , Steel Square 0.787 Shank
Picture of TUNGALOY MVQNL2020K16 Stick Tool 35.0° Insert Neg,Q/H style, 45deg Approach , Steel Square 0.787 Shank

TUNGALOY MVQNL2020K16 Stick Tool 35.0° Insert Neg,Q/H style, 45deg Approach , Steel Square 0.787 Shank

ANSI: MVQNL2020K16

ISO: MVQNL2020K16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6805506
Delivery date: 3-5 days
$172.30

Important Notes

Neg,Q/H style, 45deg Approach

Details

Multi-clamp toolholder with 117.5deg approach angle, for negative 35deg, 25deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Dimensional Specifications
Lead Angle 117.5°
Machine Side Connection Size 0.7874 20.00MM
Shank/Pilot Dia 0.7874 20.00MM
Overall Len 4.9213 125.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Insert Size Ic 16 "33"
Clearance Angle 25.0°
Cutting & Machining Properties
Insert Style VN
Hand R/L Left
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
