  • TUNGALOY JSDJCL1616H11 Stick Tool 55.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank
Picture of TUNGALOY JSDJCL1616H11 Stick Tool 55.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank

TUNGALOY JSDJCL1616H11 Stick Tool 55.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank

ANSI: JSDJCL1616H11

ISO: JSDJCL1616H11

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6804859
Delivery date: 3-5 days
$99.60

Important Notes

Posi,J style, 93deg Approach

Details

Screw-on clamp toolholder with 93deg approach angle, for positive 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Insert Application General Purpose
Shipping State Illinois
Insert Type Positive
Dimensional Specifications
Insert Size Ic 11 "32"
Clearance Angle 30.0°
Lead Angle 93°
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 3.9370 100.00MM
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Cutting & Machining Properties
Inter/Extern External
Insert Style DC
Hand R/L Left
Insert Shape/Cutter Pocket Shape 55.0°
