  • TUNGALOY DSBNL2525M12 Stick Tool Square Insert Neg,B/R style, 75deg Approach , Steel Square 0.984 Shank
Picture of TUNGALOY DSBNL2525M12 Stick Tool Square Insert Neg,B/R style, 75deg Approach , Steel Square 0.984 Shank

TUNGALOY DSBNL2525M12 Stick Tool Square Insert Neg,B/R style, 75deg Approach , Steel Square 0.984 Shank

ANSI: DSBNL2525M12

ISO: DSBNL2525M12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6803674
Delivery date: 3-5 days
$190.05

Important Notes

Neg,B/R style, 75deg Approach

Details

One-Double toolholder with 75deg approach angle, for negative square inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Package Size 1
Application Ext.Turning
Insert/Tool Tool
Dimensional Specifications
Clearance Angle 10.0°
Overall Len 5.9055 150.00MM
Machine Side Connection Size 0.9843 25.00MM
Insert Size Ic 12 "43"
Shank/Pilot Dia 0.9843 25.00MM
Lead Angle 75°
Tool Material Steel
Machine Side Connection Type Stick Tool
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Square
Hand R/L Left
Insert Style SN
Inter/Extern External
