  • TUNGALOY DDJNL3225P1506 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.984 Shank
Picture of TUNGALOY DDJNL3225P1506 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.984 Shank

TUNGALOY DDJNL3225P1506 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.984 Shank

ANSI: DDJNL3225P1506

ISO: DDJNL3225P1506

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6802939
Delivery date: 3-5 days
$190.05

Important Notes

Neg,J style, 93deg Approach

Details

One-Double toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Dimensional Specifications
Clearance Angle 27.0°
Machine Side Connection Size 0.9843 25.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 6.6929 170.00MM
Lead Angle 93°
Insert Size Ic 15 "44"
Shank/Pilot Dia 0.9843 25.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Inter/Extern External
Hand R/L Left
