  • TUNGALOY DDJNL2020K1506 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank
Picture of TUNGALOY DDJNL2020K1506 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank

TUNGALOY DDJNL2020K1506 Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank

ANSI: DDJNL2020K1506

ISO: DDJNL2020K1506

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6802935
Delivery date: 3-5 days
$178.80

Important Notes

Neg,J style, 93deg Approach

Details

One-Double toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Package Size 1
Application Ext.Turning
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 4.9213 125.00MM
Insert Size Ic 15 "44"
Lead Angle 93°
Machine Side Connection Size 0.7874 20.00MM
Shank/Pilot Dia 0.7874 20.00MM
Clearance Angle 27.0°
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Hand R/L Left
Inter/Extern External
