  • TUNGALOY CSDPN1616H3 Stick Tool Square Insert Posi,D style, 45deg Approach , Steel Square 0.629 Shank
Picture of TUNGALOY CSDPN1616H3 Stick Tool Square Insert Posi,D style, 45deg Approach , Steel Square 0.629 Shank

TUNGALOY CSDPN1616H3 Stick Tool Square Insert Posi,D style, 45deg Approach , Steel Square 0.629 Shank

ANSI: CSDPN1616H3

ISO: CSDPN1616H3

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6802486
Delivery date: 3-5 days
$107.65

Important Notes

Posi,D style, 45deg Approach

Details

Clamp-on toolholder with 45deg approach angle, for positive square inserts

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Clearance Angle 40.0°
Machine Side Connection Size 0.6299 16.00MM
Insert Size Ic 09 "32"
Overall Len 3.9370 100.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Lead Angle 45°
Shank/Pilot Dia 0.6299 16.00MM
Cutting & Machining Properties
Inter/Extern External
Insert Shape/Cutter Pocket Shape Square
Hand R/L Neutral
Insert Style SP
