  • TUNGALOY C3ADJNL22050-1104N Quick Change Stick Tool 55.0° Insert EcoTurn Toolholders , ISO 26623 1 (TungCap) , Neg,J style, 93deg Approach , Steel PSC "Capto Type" 1.181 Shank
Picture of TUNGALOY C3ADJNL22050-1104N Quick Change Stick Tool 55.0° Insert EcoTurn Toolholders , ISO 26623 1 (TungCap) , Neg,J style, 93deg Approach , Steel PSC "Capto Type" 1.181 Shank

TUNGALOY C3ADJNL22050-1104N Quick Change Stick Tool 55.0° Insert EcoTurn Toolholders , ISO 26623 1 (TungCap) , Neg,J style, 93deg Approach , Steel PSC "Capto Type" 1.181 Shank

ANSI: C3ADJNL22050-1104N

ISO: C3ADJNL22050-1104N

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6770599
Delivery date: 3-5 days
$240.73

Important Notes

EcoTurn Toolholders ISO 26623 1 (TungCap) Neg,J style, 93deg Approach

Details

TungCap Double-clamp toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Shipping State Illinois
Made In USA No
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Dimensional Specifications
Tool Material Steel
Insert Size Ic 11 "33"
Machine Side Connection Type PSC "Capt0 Type"
Shank/Pilot Dia 1.1811 30.00MM
Clearance Angle 30.0°
Overall Len 1.9690 50.01MM
Min Bore 4.8000
Machine Side Connection Size 1.1810 30.00MM
Lead Angle 93°
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Hand R/L Left
