Picture of TUNGALOY AWLNL164-A Stick Tool Trigon Insert Neg,L style, 95deg Approach , Steel Square 1.000 Shank

TUNGALOY AWLNL164-A Stick Tool Trigon Insert Neg,L style, 95deg Approach , Steel Square 1.000 Shank

ANSI: AWLNL164-A

ISO: AWLNL164-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6853121
Delivery date: 3-5 days
$128.05

Important Notes

Neg,L style, 95deg Approach

Details

Double-clamp toolholder with 95deg approach angle, for negative trigon inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Tool Material Steel
Machine Side Connection Type Stick Tool
Lead Angle 95°
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Insert Size Ic 12 "43"
Overall Len 6.0000 152.40MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Trigon
Hand R/L Left
Inter/Extern External
Insert Style WN
