  • TUNGALOY AVQNR122.33-A Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,Q/H style, 45deg Approach , Steel Square 0.750 Shank
Picture of TUNGALOY AVQNR122.33-A Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,Q/H style, 45deg Approach , Steel Square 0.750 Shank

TUNGALOY AVQNR122.33-A Stick Tool 35.0° Insert EcoTurn Toolholders , Neg,Q/H style, 45deg Approach , Steel Square 0.750 Shank

ANSI: AVQNR122.33-A

ISO: AVQNR122.33-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6759383
Delivery date: 3-5 days
$162.15

Important Notes

EcoTurn Toolholders Neg,Q/H style, 45deg Approach

Details

Double-clamp toolholders with 117.5deg approach angle for negative 35deg rhombic inserts VN**2.33...

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Shipping State Illinois
Made In USA No
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Dimensional Specifications
Insert Size Ic 12 "2.3"
Tool Material Steel
Machine Side Connection Type Stick Tool
Lead Angle 117.5°
Clearance Angle 25.0°
Overall Len 4.5000 114.30MM
Machine Side Connection Size 0.7500 19.05MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Cutting & Machining Properties
Insert Style VN
Hand R/L Right
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
