  • TUNGALOY AVJNR2020K16-A Stick Tool 35.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank
Picture of TUNGALOY AVJNR2020K16-A Stick Tool 35.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank

TUNGALOY AVJNR2020K16-A Stick Tool 35.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank

ANSI: AVJNR2020K16-A

ISO: AVJNR2020K16-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6852780
Delivery date: 3-5 days
$162.15

Important Notes

Neg,J style, 93deg Approach

Details

Double-clamp toolholder with 93deg approach angle, for negative 35deg and 25deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Machine Side Connection Size 0.7874 20.00MM
Insert Size Ic 16 "33"
Lead Angle 93°
Tool Material Steel
Machine Side Connection Type Stick Tool
Shank/Pilot Dia 0.7874 20.00MM
Clearance Angle 50.0°
Overall Len 4.9213 125.00MM
Cutting & Machining Properties
Hand R/L Right
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
Insert Style VN
