  • TUNGALOY ASSNL2525M15-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 0.984 Shank
Picture of TUNGALOY ASSNL2525M15-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 0.984 Shank

TUNGALOY ASSNL2525M15-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 0.984 Shank

ANSI: ASSNL2525M15-A

ISO: ASSNL2525M15-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6888900
Delivery date: 3-5 days
$128.05

Important Notes

Neg,S style, 45deg Approach

Details

Double-clamp toolholder with 45deg approach angle (S-style), for negative square inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Shipping State Illinois
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Insert Type Negative
Made In USA No
Dimensional Specifications
Overall Len 5.9055 150.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.9843 25.00MM
Clearance Angle 40.0°
Insert Size Ic 16 "54"
Shank/Pilot Dia 0.9843 25.00MM
Lead Angle 45°
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Square
Hand R/L Left
Insert Style CN
Inter/Extern External
