Picture of TUNGALOY ASSNL245-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 1.500 Shank

TUNGALOY ASSNL245-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 1.500 Shank

ANSI: ASSNL245-A

ISO: ASSNL245-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6990767
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Important Notes

Neg,S style, 45deg Approach

Details

Double-clamp toolholder with 45deg approach angle (S-style), for negative square inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Machine Side Connection Type Stick Tool
Clearance Angle 40.0°
Lead Angle 45°
Machine Side Connection Size 1.5000 38.10MM
Shank/Pilot Dia 1.5000 38.10MM - 1-1/2
Overall Len 8.0000 203.20MM
Insert Size Ic 16 "54"
Tool Material Steel
Cutting & Machining Properties
Insert Style CN
Inter/Extern External
Insert Shape/Cutter Pocket Shape Square
Hand R/L Left
