Picture of TUNGALOY ASSNL206-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 1.250 Shank

TUNGALOY ASSNL206-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 1.250 Shank

ANSI: ASSNL206-A

ISO: ASSNL206-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6990769
Delivery date: 3-5 days
$192.05

Important Notes

Neg,S style, 45deg Approach

Details

Double-clamp toolholder with 45deg approach angle (S-style), for negative square inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Insert Application General Purpose
Insert Type Negative
Made In USA No
Dimensional Specifications
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Insert Size Ic 19 "64"
Clearance Angle 40.0°
Overall Len 7.0000 177.80MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 1.2500 31.75MM
Lead Angle 45°
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Square
Hand R/L Left
Inter/Extern External
Insert Style SN
