Picture of TUNGALOY ASSNL164-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 1.000 Shank

TUNGALOY ASSNL164-A Stick Tool Square Insert Neg,S style, 45deg Approach , Steel Square 1.000 Shank

ANSI: ASSNL164-A

ISO: ASSNL164-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6853113
Delivery date: 3-5 days
$128.05

Important Notes

Neg,S style, 45deg Approach

Details

Double-clamp toolholder with 45deg approach angle (S-style), for negative square inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Application Ext.Turning
Package Size 1
Dimensional Specifications
Lead Angle 45°
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Insert Size Ic 12 "43"
Overall Len 6.0000 152.40MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Clearance Angle 40.0°
Cutting & Machining Properties
Hand R/L Left
Insert Style SN
Insert Shape/Cutter Pocket Shape Square
Inter/Extern External
