Picture of TUNGALOY ASKNL124-A Stick Tool Square Insert Neg,K style, 75deg Approach , Steel Square 0.750 Shank

TUNGALOY ASKNL124-A Stick Tool Square Insert Neg,K style, 75deg Approach , Steel Square 0.750 Shank

ANSI: ASKNL124-A

ISO: ASKNL124-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6864726
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Important Notes

Neg,K style, 75deg Approach

Details

Double-clamp toolholder with 75deg approach angle, for negative square inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Shipping State Illinois
Insert Application General Purpose
Insert Type Negative
Made In USA No
Application Ext.Turning
Package Size 1
Dimensional Specifications
Machine Side Connection Size 0.7500 19.05MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Clearance Angle 10.0°
Lead Angle 75° F
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Insert Size Ic 12 "43"
Overall Len 4.5000 114.30MM
Cutting & Machining Properties
Insert Style SN
Insert Shape/Cutter Pocket Shape Square
Hand R/L Left
Inter/Extern External
