Picture of TUNGALOY ADJNR164-A Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 1.000 Shank

TUNGALOY ADJNR164-A Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 1.000 Shank

ANSI: ADJNR164-A

ISO: ADJNR164-A

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6853108
Delivery date: 3-5 days
$128.05

Important Notes

Neg,J style, 93deg Approach

Details

Double-clamp toolholder with 93deg approach angle, for negative 55deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Package Size 1
Dimensional Specifications
Insert Size Ic 12 "43"
Clearance Angle 27.0°
Lead Angle 93°
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 5.9100 150.11MM
Cutting & Machining Properties
Inter/Extern External
Hand R/L Right
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
