  • TUNGALOY ADJNR12-4-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.750 Shank
Picture of TUNGALOY ADJNR12-4-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.750 Shank

TUNGALOY ADJNR12-4-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.750 Shank

ANSI: ADJNR12-4-CHP-MC

ISO: ADJNR12-4-CHP-MC

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN3346701
Delivery date: 3-5 days
$274.10

Important Notes

Neg,J style, 93deg Approach

Details

Double-clamp toolholders with 93deg approach angle for negative 55deg rhombic inserts with high pressure coolant channels

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Clearance Angle 27.0°
Lead Angle 93°
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Overall Len 4.5000 114.30MM
Insert Size Ic 12 "43"
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.7500 19.05MM
Cutting & Machining Properties
Inter/Extern External
Hand R/L Right
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
