  • TUNGALOY ADJNL2020X-15-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank
Picture of TUNGALOY ADJNL2020X-15-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank

TUNGALOY ADJNL2020X-15-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.787 Shank

ANSI: ADJNL2020X-15-CHP-MC

ISO: ADJNL2020X-15-CHP-MC

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN3346697
Delivery date: 3-5 days
$274.10

Important Notes

Neg,J style, 93deg Approach

Details

Double-clamp toolholders with 93deg approach angle for negative 55deg rhombic insert with high pressure coolant channels. High-pressure coolant capability with tube and direct connection.

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Overall Len 4.3307 110.00MM
Clearance Angle 27.0°
Insert Size Ic 12 "43"
Machine Side Connection Size 0.7874 20.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Lead Angle 93°
Shank/Pilot Dia 0.7874 20.00MM
Cutting & Machining Properties
Inter/Extern External
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Hand R/L Left
