  • TUNGALOY ADJNL12-4-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.750 Shank
Picture of TUNGALOY ADJNL12-4-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.750 Shank

TUNGALOY ADJNL12-4-CHP-MC Stick Tool 55.0° Insert Neg,J style, 93deg Approach , Steel Square 0.750 Shank

ANSI: ADJNL12-4-CHP-MC

ISO: ADJNL12-4-CHP-MC

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN3346702
Delivery date: 3-5 days
$274.10

Important Notes

Neg,J style, 93deg Approach

Details

Double-clamp toolholders with 93deg approach angle for negative 55deg rhombic inserts with high pressure coolant channels

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Clearance Angle 27.0°
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.7500 19.05MM
Lead Angle 93°
Overall Len 4.5000 114.30MM
Insert Size Ic 12 "43"
Cutting & Machining Properties
Inter/Extern External
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Hand R/L Left
