  • TUNGALOY A16Q-SCLCL09-D180 Boring Bar 80.0° Insert Posi,L style, 95deg Approach , Steel Round 0.629 Shank
Picture of TUNGALOY A16Q-SCLCL09-D180 Boring Bar 80.0° Insert Posi,L style, 95deg Approach , Steel Round 0.629 Shank

TUNGALOY A16Q-SCLCL09-D180 Boring Bar 80.0° Insert Posi,L style, 95deg Approach , Steel Round 0.629 Shank

ANSI: A16Q-SCLCL09-D180

ISO: A16Q-SCLCL09-D180

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6848810
Delivery date: 3-5 days
$194.70

Important Notes

Posi,L style, 95deg Approach

Details

Screw-on boring bars, for Posi 80deg rhombic insert with 7 deg clearance

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Type Positive
Application Int.Turning
Package Size 1
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Dimensional Specifications
Tool Material Steel
Lead Angle 95°
Machine Side Connection Size 0.6299 16.00MM
Min Bore 0.7087
Shank/Pilot Dia 0.6299 16.00MM
Insert Size Ic 09 "32"
Machine Side Connection Type Boring Bar
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 80.0°
Insert Style CC
Inter/Extern Internal
