  • TUNGALOY A10-SCLCL3-D14 Boring Bar 80.0° Insert Posi,L style, 95deg Approach , Steel Round 0.625 Shank
Picture of TUNGALOY A10-SCLCL3-D14 Boring Bar 80.0° Insert Posi,L style, 95deg Approach , Steel Round 0.625 Shank

TUNGALOY A10-SCLCL3-D14 Boring Bar 80.0° Insert Posi,L style, 95deg Approach , Steel Round 0.625 Shank

ANSI: A10-SCLCL3-D14

ISO: A10-SCLCL3-D14

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6862382
Delivery date: 3-5 days
$194.70

Important Notes

Posi,L style, 95deg Approach

Details

Screw-on boring bars, for Posi 80deg rhombic insert with 7 deg clearance

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Int.Turning
Insert Application General Purpose
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Package Size 1
Dimensional Specifications
Lead Angle 95°
Min Bore 0.8750
Insert Size Ic 09 "32"
Machine Side Connection Type Boring Bar
Tool Material Steel
Machine Side Connection Size 0.6250 15.88MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 80.0°
Insert Style CC
Inter/Extern Internal
