Tool-FLO FLFT-4250L GP3 Top Notch Face Grooving Insert TiN 0.250 Wide 0.020 Corner Radius

ANSI: FLFT-4250L GP3

ISO: FLFT-4250L GP3

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TOOL-FLO
SKU: TOO6349250LGP3
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Details

General purpose face grooving

Grade and Coating Description

PVD TiN grade with a wear resistant micro-grain substrate. Excellent choice in stainless steels, high-temperature alloys, aerospace materials, and non-ferrous materials. Good in standard steels at low to medium SFM.

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Coating TiN
Made In USA Yes
Shipping State Texas
Insert Application General Purpose
Grade GP3
Insert/Tool Insert
Application Grooving & Parting Insert
Package Size 10
Dimensional Specifications
Cut Rating <53HRC Steel, Aluminum, Gray Iron, High Temp, Stainless Steel
Insert Size Ic 4
Depth Of Cut Max 0.5500
Cutting Width 0.2500 6.35MM
Corner Radius 0.0200 0.51MM - 0.0250 0.64MM
Cutting & Machining Properties
Insert Style TOP NOTCH
Cutting Edge Mat Carbide
Insert Shape/Cutter Pocket Shape Top Notch
