Picture of Tool-FLO AL075-3R Threading Stick Tool Iso Thread Square 0.750 Right

Tool-FLO AL075-3R Threading Stick Tool Iso Thread Square 0.750 Right

ANSI: AL075-3R

ISO: AL075-3R

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TOOL-FLO
SKU: TOO916056361
Delivery date: 3-5 days
$86.25
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Shipping State Texas
Insert Application General Purpose
Made In USA Yes
Application Ext.Threading, Ext.Groove Threading
Package Size 1
Insert/Tool Insert
Dimensional Specifications
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Insert Size Ic 16
Overall Len 5.0000 127.00MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.7500 19.05MM
Tool Width 0.7500
Tool Over Hang 1.2000
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Inter/Extern External
Insert Style ISO
Hand R/L Right
Seat/Nest YE3
Fasteners & Connectors
Seat Screw SY3
Insert Screw SA3
