Picture of SANDVIK SPEX 15 04 ED R-1 530 T-Max Milling Insert ModulMill 90, Rhombic Insert

SANDVIK SPEX 15 04 ED R-1 530 T-Max Milling Insert ModulMill 90, Rhombic Insert

ANSI: SPEX 15 04 ED R-1 530

ISO: SPEX 15 04 ED R-1 530

Need Assistance or Service? Please call 262-251-4020

Manufacturer: SANDVIK
SKU: SAN5751005
Delivery date: 3-5 days
$21.43

Cutting Edge Definition

Cermet is a cutting material combining ceramics and metals (usualט Nickel). The result is a harder substrate than carbide, therefore more wear-resistant, and enables machining at higher cutting speeds. The downside is very low toughness, and therefore, it is used only for finishing applications in stable conditions. Some tougher versions are available today for semi roughing. Used very often in Duplex milling.

Details

SPEX 15 04 ED R-1 530 Sandvik T-Max®, Cermet Insert for Milling, Uncoated

Grade and Coating Description

CERMET FOR STEEL AND STAINLESS

Products specifications
Attribute name Attribute value
General Product Information
Grade 530
Insert Type Positive
Insert/Tool Insert
Application Milling Insert
Insert Application Medium
Package Size 10
Shipping State Illinois
Made In USA No
Dimensional Specifications
Depth Of Cut Max 0.4724
Cut Rating <40HRC Steel, Stainless Steel
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Square
Hand R/L Right
Cutting Edge Mat Cermet
Insert Style SP
