Picture of SANDVIK R390-025C5-11M095, CoroMill 390 Square Shoulder Milling Cutter, 25mm Cutting Diameter

SANDVIK R390-025C5-11M095, CoroMill 390 Square Shoulder Milling Cutter, 25mm Cutting Diameter

ANSI: R390-025C5-11M095

ISO: R390-025C5-11M095

Need Assistance or Service? Please call 262-251-4020

Manufacturer: SANDVIK
SKU: SAN5745437
Delivery date: 3-5 days
$560.32
Products specifications
Attribute name Attribute value
General Product Information
Application Ramp Milling, Slot Milling, Pocket Milling, Side Milling, Face Milling
Insert Application Roughing, Semi Finishing
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Insert Type Positive
Package Size 1
Dimensional Specifications
Depth Of Cut Max 0.3940
Machine Side Connection Size 1.9685 50.00MM
Shank/Pilot Dia 1.9685 50.00MM
Machine Side Connection Type PSC "Capt0 Type"
Flutes/Inserts 3
Tool Material Steel
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style R390
Hand R/L Right
Cool Sply Type Internal
Coolant Thru Yes
