ROMAY RNGN 32 CC-513 Turning Insert Round Silicon Nitride 0.375 Corner Radius

ANSI: RNGN32 CC-513

ISO: RNGN090300 CC-513

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ROMAY
SKU: ROMRNGN090300 CC-513
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Silicon nitrides (Si3N4) feature an excellent combination of material properties. They are nearly as light as silicon carbide (SiC), but their microstructure gives them excellent thermal shock resistance and their high fracture toughness makes them resistant to impacts and shocks. Used at high speeds up to 4,000 sfm in cast iron machining.

Grade and Coating Description

Our toughest silicon nitride grade. Great for high-speed iron cutting with very heavy interruptions in milling, turning, boring facing.

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Insert
Application Int.Turning, Ext.Turning
Insert Type Negative
Grade CC-513
Made In USA No
Insert Application Finishing, Semi Finishing
Shipping State Michigan
Package Size 10
Dimensional Specifications
Corner Radius 0.3750 9.53MM
Cut Rating Ductile Iron, Gray Iron
Insert Size Ic 09 "32"
Cutting & Machining Properties
Insert Style RN
Cutting Edge Mat Silicon Nitride
Insert Shape/Cutter Pocket Shape Round
