ROMAY CNGA 643 CC-519 Turning Insert 80.0° Silicon Nitride 0.047 Corner Radius

ANSI: CNGA643 CC-519

ISO: CNGA190612 CC-519

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ROMAY
SKU: ROMCNGA190612 CC-519
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Silicon nitrides (Si3N4) feature an excellent combination of material properties. They are nearly as light as silicon carbide (SiC), but their microstructure gives them excellent thermal shock resistance and their high fracture toughness makes them resistant to impacts and shocks. Used at high speeds up to 4,000 sfm in cast iron machining.

Products specifications
Attribute name Attribute value
General Product Information
Application Int.Turning, Ext.Turning
Grade CC-519
Shipping State Michigan
Insert Type Negative
Insert Application Roughing
Made In USA No
Insert/Tool Insert
Package Size 10
Dimensional Specifications
Insert Size Ic 19 "64"
Corner Radius 0.0470 1.19MM
Cut Rating Ductile Iron, Gray Iron
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 80.0°
Cutting Edge Mat Silicon Nitride
Insert Style CN
