ROBBJACK TM-203-06 DIA 3/16 SH 0.2500 LOC 0.1875 OAL 0.7500 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Corner Radius 0.0400 1.02MM

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ROBBJACK
SKU: ROBTM-203-06
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA Yes
Application Face Milling, Copy Milling, Feed Milling, Profile Milling, Slot Milling
Package Size 1
Performance Rating High Performance
Shipping State California
Dimensional Specifications
Neck Length 0.7500 19.05MM
Helix Angle 30°
Length Of Cut 0.1875 4.76MM
Single/Double End Single End
Cutter Dia 0.1875 4.76MM - 3/16
Cutter Style Carbide Bull Nose Finisher
Flutes/Inserts 2
Length Type Standard
Dimension Description 0.188 x 0.250 x 0.188 x 0.750
Cut Rating <65HRC Steel, Stainless Steel
Tool Material Carbide
Machine Side Connection Type Cylindrical
Machine Side Connection Size 0.2500 6.35MM
Inch/Metric Inch
Corner Radius 0.0400 1.02MM
Shank/Pilot Dia 0.2500 6.35MM - 1/4 - E
Overall Len 0.7500 19.05MM
End Of Tool Shape Corner Radius
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
Center Cutting Yes
Industry-Specific Applications
Job Shop Yes
